EcoComfort Plus

The EcoComfort Plus is a ventilation system that ensures continuous fresh air indoors without opening windows, preventing humidity and mould. A high-efficiency ceramic heat exchanger stores heat from outgoing air and transfers it to incoming air, recovering heat and reducing energy waste.

Product Overview

  • A high-efficiency regenerative ceramic heat exchanger, placed inside the unit, accumulates the heat released by the air flow extracted from the room and returns it by heating the air during the intake cycle, thus recovering the output heat and avoiding energy waste.
  • EcoComfort Plus is equipped with an ISO COARSE efficiency class filter which retains any impurities from the air released into the environment and a low consumption brushless DC motor controlled by a microprocessor which processes the information from the sensors present on the unit: temperature, VOC (Volatile Organic Compounds), humidity and light brightness. All these sensors allow the unit to adopt the most suitable ventilation modes automatically and ensure the best environmental comfort.
  • The remote control allows for simple and intuitive configuration during installation and easy use by the end user. Infrared (IR) technology allows immediate communication with the device and the user can easily manage the sensors with which the unit is equipped and obtain information regarding the current operating mode. By installing multiple units, a single remote control will be enough to control them all.
  • EcoComfort Plus is available in two diameters (100 mm and 160 mm) and must be installed on the perimeter walls.

Product Features

Features
  • Body made in antistatic ABS plastic.
  • Operating temperature -20 ° C to 50 ° C.
  • Compact dimensions and easy to install.
  • Telescopic body to fit every wall thickness.
  • External grille easy to install either from indoor or outdoor.
  • ISO Coarse filter.
  • Flow rectifier to grant higher performances, only for 160mm models.
  • Infrared (IR) remote control
  • LED signalling in the lower part of the front body.
  • Temperature, VOC air quality, humidity and twilight sensors.
  • In compliance to UE Reg. 1254/2014.



Heat Recovery Unit
  • Ventilating unit with DC Brushless motor.
  • PVC shockproof telescopic body.
  • Ceramic heat exchanger with efficiency >90%.
  • Cross-linked polyurethane filter, ISO Coarse filtration class according to EN799.
  • Flow straightener to ensure higher performances, only for version with 160 mm diameter.
  • Power supply 110V ÷ 230V~ 50/60Hz.
  • LED signalling in the lower part of the front body.
  • Temperature, VOC, humidity and brightness sensors.
  • Splash proof protection class: IPX4.

Data Sheet
